Photos show the actual item you will receive.
Product details
About this part
The Thorlabs M940L3 940nm 800mW Mounted LED Light Source 1000mA is made by Thorlabs and identified by manufacturer part number M940L3.
This listing is for the exact part number stated above. Compare the part number, condition and photos with your equipment before ordering.
Condition
This item is listed as Used. Previously used. See condition notes and photos.
The photos are part of the description — check them for labels, connectors, markings and any visible wear.
What's included
1 × Thorlabs M940L3 940nm 800mW Mounted LED Light Source 1000mA.
Only the items listed here or clearly shown in the photos are included. Cables, manuals, mounting hardware and accessories are not included unless stated.
Identification & compatibility
Check the manufacturer (Thorlabs), the part number (M940L3) and the photos against your equipment. If you are not sure this is the right part, contact us before you order.
Price match
Found an identical item for less at a fixed price elsewhere? Contact us before you buy with the details, and we will review it.
Important information
Product information is based on what is available for this specific item. Where specifications or compatibility are critical to your application, confirm them before purchase.
- Brand
- Thorlabs
- Part number
- M940L3
- Model
- M940L3
- Country of Origin
- United States
- Serial number (label)
- M00838221
- Nominal wavelength
- 940 nm (peak 950 nm typ.)
- Bandwidth (FWHM)
- 37 nm
- LED output power
- 800 mW min, 1000 mW typ. at 1000 mA
- Maximum current (CW)
- 1000 mA
- Forward voltage
- 2.75 V typ.
- Emitter size / viewing angle
- 1 x 1 mm / 90° full angle
- Heat sink
- Ø30.5 mm, SM1 (1.035"-40) internal thread, 6 mm deep
- Cable on this unit
- Modified: white rectangular plug, not the Thorlabs M8 connector
- Photobiological risk group
- RG0 - Exempt (IEC 62471:2006)
- Condition
- Used
This is a Thorlabs M940L3 mounted LED: a 940 nm infrared LED on a finned 30.5 mm heat sink, rated by Thorlabs at 800 mW minimum output with a 1000 mA maximum drive current. Condition: used. The label on the back reads THORLABS M940L3, M00838221, CE.
What are the M940L3 specifications?
Per the Thorlabs spec sheet: nominal wavelength 940 nm (peak 950 nm typical), bandwidth 37 nm FWHM, output 800 mW minimum and 1000 mW typical at 1000 mA, forward voltage 2.75 V typical, 1 x 1 mm emitter, 90° viewing angle, and SM1 (1.035"-40) internal thread at the front of the heat sink. Thorlabs rates it Risk Group RG0 (exempt) under IEC 62471.
Is the cable original?
No. Thorlabs fits the M940L3 with a cable ending in a 4-pin M8 circular connector (pins 1 and 2 for the LED, pins 3 and 4 for an internal EEPROM). On this unit the cable ends in a white rectangular plug, with a tag reading "TO WA86050". A Thorlabs driver needs the M8 plug, so plan to refit one or use your own constant-current supply.
How do you drive a 940 nm mounted LED?
With a constant current source that does not exceed 1000 mA and can supply 2.75 V. Thorlabs recommends its DC2200 or LEDD1B LED drivers, or the DC4100/DC4104 with the DC4100-HUB. Give the cooling fins free air: Thorlabs notes the case can run up to 25 °C above ambient.
What is in the photos?
The LED head with a Thorlabs lens ring fitted in the front thread, the short black cable with the white plug, and the label on the back of the heat sink.
- Ships from
- Israel
- Tracking
- Included on every order
Import duties and taxes may apply in your country and are paid by the buyer on delivery.
- Returns
- Not accepted
Return terms differ from item to item — this item's own policy is shown above.
Whatever it says, an item that arrives faulty or not as described is covered: tell us within 30 days of delivery and we will refund or replace it.
Consumers in the EU, the UK and Israel keep their legal right to cancel within 14 days. Full details and the return request form are on our Returns and warranty page.
Questions about this part
What is the Thorlabs M940L3?
A Thorlabs mounted LED at 940 nm (infrared), rated 800 mW minimum output at 1000 mA, on a heat sink with SM1 thread.
Which Thorlabs LED driver works with the M940L3?
Thorlabs recommends the DC2200 or LEDD1B, or the DC4100/DC4104 with the DC4100-HUB. These use the M8 connector, which this unit's modified cable does not have.
What current does the M940L3 need?
A constant current of up to 1000 mA, at a forward voltage of about 2.75 V.
Can I mount optics on it?
Yes. The heat sink has an SM1 (1.035"-40) internal thread for lens tubes and collimation optics. A lens ring is already fitted on this unit.
Is the 940 nm light visible?
Thorlabs classes it as IR. The spectrum peaks at about 950 nm, outside the visible range.
