Photos show the actual item you will receive.
Product details
About this part
The Horiba HE-480R-DC24V Resist Meter is made by Horiba and identified by manufacturer part number HE-480R-DC24V.
This listing is for the exact part number stated above. Compare the part number, condition and photos with your equipment before ordering.
Condition
This item is listed as Used. Previously used. See condition notes and photos.
The photos are part of the description — check them for labels, connectors, markings and any visible wear.
What's included
1 × Horiba HE-480R-DC24V Resist Meter.
Only the items listed here or clearly shown in the photos are included. Cables, manuals, mounting hardware and accessories are not included unless stated.
Identification & compatibility
Check the manufacturer (Horiba), the part number (HE-480R-DC24V) and the photos against your equipment. If you are not sure this is the right part, contact us before you order.
Price match
Found an identical item for less at a fixed price elsewhere? Contact us before you buy with the details, and we will review it.
Important information
Product information is based on what is available for this specific item. Where specifications or compatibility are critical to your application, confirm them before purchase.
- Brand
- Horiba
- Part number
- HE-480R-DC24V
- Country of Origin
- Japan
- Manufacturer
- HORIBA Advanced Techno Co., Ltd., Kyoto, Japan
- Model
- HE-480R-DC24V (front: HE-480R-DC)
- Type
- Industrial resistivity meter, panel mount
- Power (label)
- 24 V DC, 5 W max
- Measuring range
- 0 to 0.200 / 2.00 / 20.00 / 100.0 MΩ·cm
- Temperature range
- 0 to 100 °C, Pt1000 sensor
- Repeatability / linearity
- ±0.5% of full scale each
- Compatible sensor
- 2-electrode, cell constant 0.01/cm (HORIBA ERD/ERF series)
- Transmission output
- 4-20 mA DC, isolated, max. load 900 Ω
- Contact outputs
- 2 x SPDT relay (R1, R2), 240 V AC 3 A / 30 V DC 3 A
- Dimensions
- 48 x 96 x 115 mm (W x H x D)
- Front protection
- IP65 (rear case IP20)
- Date (label)
- Mar 2010
- Markings
- CE, WEEE, FCC Part 15, Made in Japan
The Horiba HE-480R-DC24V is a 48 x 96 mm panel-mount resistivity meter ("Resist Meter") from HORIBA Advanced Techno that monitors the resistivity of ultrapure and DI water, here in the 24 V DC version. It works with a 2-electrode resistivity sensor with cell constant 0.01/cm and a Pt1000 temperature element, shows resistivity and temperature on two LED displays, and sends the value to a PLC or recorder over an isolated 4-20 mA output. Typical uses listed by HORIBA are ultrapure water monitoring in semiconductor, electronics, food and pharmaceutical plants. The part number is also searched as HE-480R-DC and HE480R.
What does the label say?
Model HE-480R-DC24V, HGS No. YHWJA1EW, Power 24V DC 5W (MAX), Date Mar 2010, HORIBA Advanced Techno Co., Ltd., Kyoto, Made in Japan, with CE, WEEE and FCC Part 15 markings. The front panel reads RESIST METER HE-480R-DC.
What is the difference between resistivity and conductivity?
They are the same measurement inverted: resistivity (MΩ·cm) is 1 divided by conductivity (µS/cm). Resistivity is the usual unit for high-purity water because the numbers are easier to read; theoretically pure water at 25 °C is about 18.2 MΩ·cm. The HE-480R measures 0 to 100.0 MΩ·cm and lets you set the pure-water reference to 18.23 (standard), 18.18 or 18.24 MΩ·cm.
How is it wired?
The rear terminal block, shown in the photos, has relay R1 and relay R2 (each C, NO, NC), the mA + and - transmission output, the DC + and - supply, a ground terminal, and the sensor terminals 1, 2, T, T and E. HORIBA rates the relay contacts at 240 V AC 3 A or 30 V DC 3 A (resistive load).
What is in the photos?
The meter from the front with its panel-mount brackets, the rating label on the case, and the rear terminal block under its clear cover. Condition: used.
- Ships from
- Israel
- Tracking
- Included on every order
Import duties and taxes may apply in your country and are paid by the buyer on delivery.
- Returns
- Not accepted
Return terms differ from item to item — this item's own policy is shown above.
Whatever it says, an item that arrives faulty or not as described is covered: tell us within 30 days of delivery and we will refund or replace it.
Consumers in the EU, the UK and Israel keep their legal right to cancel within 14 days. Full details and the return request form are on our Returns and warranty page.
Questions about this part
What is the Horiba HE-480R-DC24V?
A panel-mount industrial resistivity meter from HORIBA Advanced Techno for ultrapure and DI water, in the 24 V DC power version.
What power supply does it need?
24 V DC, 5 W maximum, as printed on the rating label.
What is the difference between resistivity and conductivity?
Resistivity is the inverse of conductivity. For high-purity water it is shown in MΩ·cm; pure water at 25 °C is about 18.2 MΩ·cm.
What range does it measure?
0 to 100.0 MΩ·cm in four ranges, with temperature measured from 0 to 100 °C.
What sensor does it work with?
A 2-electrode resistivity sensor with cell constant 0.01/cm and Pt1000 temperature element; HORIBA lists its ERD/ERF series. No sensor is shown in the photos.
What outputs does it have?
An isolated 4-20 mA transmission output and two SPDT relay contacts (R1, R2) for limits or alarms.
What condition is it in?
Used. The label is dated March 2010.
