Photos show the actual item you will receive.
Product details
About this part
The DWYER DPT-A04 50853287 Digital Pressure Transmitter with Switche is made by DWYER and identified by manufacturer part number DPT-A04.
This listing is for the exact part number stated above. Compare the part number, condition and photos with your equipment before ordering.
Condition
This item is listed as Used. Previously used. See condition notes and photos.
The photos are part of the description — check them for labels, connectors, markings and any visible wear.
What's included
1 × DWYER DPT-A04 50853287 Digital Pressure Transmitter with Switche.
Only the items listed here or clearly shown in the photos are included. Cables, manuals, mounting hardware and accessories are not included unless stated.
Identification & compatibility
Check the manufacturer (DWYER), the part number (DPT-A04) and the photos against your equipment. If you are not sure this is the right part, contact us before you order.
Price match
Found an identical item for less at a fixed price elsewhere? Contact us before you buy with the details, and we will review it.
Important information
Product information is based on what is available for this specific item. Where specifications or compatibility are critical to your application, confirm them before purchase.
- Brand
- DWYER
- Part number
- DPT-A04
- Country of Origin
- Germany
- Series
- Dwyer Series DPT digital pressure transmitter with switches
- Range
- 0 to 50 psig (3.447 bar)
- Maximum pressure
- 100 psig
- Burst pressure
- 250 psig
- Output signal
- 4–20 mA, loop resistance ≤ 0.5 kΩ
- Switches
- Two PNP solid-state (SP1, SP2), 250 mA
- Power
- 15–35 VDC
- Accuracy
- 1.0% F.S. (non-linearity, hysteresis, zero point)
- Thermal effect
- 0.2% F.S. / 10 K
- Display
- Red LED, 4-digit, 14-segment
- Electrical connection
- M12 × 1, 5-pin
- Process connection
- 1/4 in male NPT
- Wetted materials
- 316L stainless steel connection and sensor
- Temperature limits
- 0 to 80 °C (32 to 176 °F)
- Enclosure rating
- IP67
- Weight
- 0.2 kg (7 oz)
- Dwyer P#
- 50853287
- Approvals
- CE
The Dwyer DPT-A04 is a Series DPT digital pressure transmitter with switches, reading 0 to 50 psig and giving a 4–20 mA output plus two programmable PNP switch outputs. The unit label reads Type DPT-A04, 0…50 psig, P# 50853287, made in Germany. Dwyer's Series DPT combines a 4-digit red LED display, two solid-state switches and a thin-film piezoresistive sensor in one compact housing for compatible gases, liquids or vapours. Buyers search for it as DPT-A04 or Dwyer 50853287.
How is the DPT-A04 wired?
The side label shows a 15–35 V DC supply on pin 1 and 0 V on pin 3, the 4–20 mA signal on pin 5, and the SP1 and SP2 switch outputs. Connection is through an M12 × 1, 5-pin connector; Dwyer's matching cable is the A-195, a 2 m shielded cable with a 5-pin female M12 connector.
Where is it used?
Dwyer lists calibration, hydraulics and pneumatics, machine tools, compressors and pumps, and machine building. The display and electrical connection rotate independently, so the reading stays visible whatever the mounting orientation.
What condition is it in?
Used. The photos show the display head with SP1, SP2, INFO and MENU keys, the stainless body and M12 connector, and an additional fitting attached to the process connection with thread-seal tape.
- Ships from
- Israel
- Tracking
- Included on every order
Import duties and taxes may apply in your country and are paid by the buyer on delivery.
- Returns
- Accepted within 60 days of delivery
- Return shipping
- Paid by the buyer
- Refund
- Money back
Return terms differ from item to item — this item's own policy is shown above.
Whatever it says, an item that arrives faulty or not as described is covered: tell us within 30 days of delivery and we will refund or replace it.
Consumers in the EU, the UK and Israel keep their legal right to cancel within 14 days. Full details and the return request form are on our Returns and warranty page.
Questions about this part
What does A04 mean in DPT-A04?
In Dwyer's Series DPT table, the A models have a 4–20 mA output and range code 04 is 0 to 50 psig. The V models have a 0–10 V output instead.
What pressure can the DPT-A04 withstand?
Dwyer lists a maximum pressure of 100 psig and a burst pressure of 250 psig for the 0–50 psig range.
What type are the switch outputs?
Two PNP solid-state switches rated 250 mA, set as SP1 and SP2.
What cable fits the DPT-A04?
Any 5-pin female M12 cable. Dwyer offers the A-195, 2 m shielded.
What supply voltage does it need?
15 to 35 V DC, per the unit label and Dwyer's specifications.
